Filter Pot MINI
The All-In-One Filter Pot MINI combines all the functions of a:
- Dosing pot
- Dirt and air separator
- Magnetic in line filter
- Cartridge filter
- Plus more features that comply with BSRIA guidelines
Technical information
Maximum system working pressure
10 Bar
Suitable for system volumes up to
90,000 litres
Flow rate through vessel
0.08 L/sec to 1.04 L/sec (4.8 L/min to 60 L/min)
Temperature range
0°C to 110°C
Filtration rate
Down to 0.5 micron
Dirty flow inlet connection
1″ BSP female
Clean return outlet connection
1″ BSP male
Dosing capacity
5.5 Litres
Filter body mounting
Wall mounted
Vessel body
304 SS (complies with PED SEP 2014/68/EU
Magnets x4
Neodymium Rare Earth
Catridge Filter (1 x 0.5 micron - supplied with Filter Pot Mini
Nylon spun bonded fibre (50,20, 5 and 0.5 micron available as spare replacements in packs of 2)
Isolation valves, NRV and fittings
304 SS
Automatic air vent
304 SS / 110°C / 10 Bar max working pressure
Line drawings
Installation schematics
Download the Filter Pot MINI data sheet
Find out more information by downloading the data sheet below.
